Excise label rewinding and validation machine

Client

Trialto Latvia

Project date

10. June, 2018

Quality control of excise stamp codes, as well as order assembly and control of corresponding numbers.

Tasks

  • Validate excise stamps at a rate of not less than 10 stickers per second
  • Perform 2 code quality check on excise stamps
  • Check a sequence of a code number string
  • Divide the ordered excise stamps by order numbers
  • In case of errors, stop the process and indicate the damaged brand
  • Receive a task and transfer the data to a common database

Solutions

  • Datalogic Matrix 300N code reading camera
  • Schneider M221 controller
  • A program that visualizes code reading and task
  • Sticker rewinder MC11 +

Benefits

  • Faster and safer validation of excise stamps
  • Both codes on the excise stamp are registered and linked
  • Accounting of order number and excise stamps used for customs documents
  • Reduced human resources in the relevant production process
  • Validation of different excise stamps
